Phidgets InterfaceKit 2/2/2
- I/O board for connecting digital and analog sensors
- 2 analog inputs, 2 digital inputs, and 2 digital Outputs
Description
The PhidgetInterfaceKit 2/2/2 is a compact, general-purpose I/O board for interfacing with digital and analog sensors. It features 2 analog inputs, 2 digital inputs, and 2 digital outputs, and connects directly to a computer via USB (Mini-USB).
The analog inputs measure voltage signals in the 0–5 V DC range. Many common sensors (temperature, humidity, pressure, etc.) output signals in exactly this range. The digital inputs are suitable for push buttons, limit switches, relays, and other logic-level outputs; built-in hardware filtering prevents false triggering caused by electrical noise. The digital outputs can be used to drive LEDs, solid-state relays, and other logic-level devices.
The included 12-wire harness exposes the connectors externally and reduces the physical footprint of the controller.
Key Features
- 2 analog inputs with data rates up to 1000 Hz
- 2 active-low digital inputs (max. 15 V DC)
- 2 digital outputs (5 V DC)
- Compact form factor – plugs directly into a USB port
- 12-wire harness included
| Technical Specifications | |
| Controlled By | USB (Mini-USB) |
| USB Stack | HID |
| Driver Support | Phidget21, Phidget22 |
| USB Voltage Min | 4.6 V DC |
| USB Voltage Max | 5.5 V DC |
| Current Consumption Min | 20 mA |
| Current Consumption Max | 500 mA |
| Available External Current | 480 mA |
| USB Speed | Full Speed |
| Operating Temperature Min | 0 °C |
| Operating Temperature Max | 70 °C |
| Analog Inputs | |
| Number of Analog Inputs | 2 |
| Resolution | 10 bit |
| Input Impedance | 900 kΩ |
| Input Voltage Min | 0 V DC |
| Input Voltage Max | 5 V DC |
| 5V Reference Error Max | 0.5 % |
| Update Rate Min | 1 sample/s |
| Update Rate Max | 1000 samples/s |
| Update Rate Max (WebService) | 62.5 samples/s |
| Digital Inputs | |
| Number of Digital Inputs | 2 |
| Input Type | Active Low |
| Pull-up Resistance | 15 kΩ |
| Low Voltage Max (True) | 800 mV DC |
| High Voltage Min (False) | 2.1 V DC |
| Low Voltage Trigger Length Min | 4 ms |
| High Voltage Trigger Length Min | 15 ms |
| Digital Input Voltage Max | ± 15 V DC |
| Update Rate | 125 samples/s |
| Digital Outputs | |
| Number of Digital Outputs | 2 |
| Series Resistance | 300 Ω |
| Digital Output Available Current | 16 mA |
| Digital Output Voltage Min | 0 V DC |
| Digital Output Voltage Max | 5 V DC |
| Customs Information | |
| Country of Origin | CN (China) |
| Canadian HS Export Code | 8471.80.00 |
| American HTS Import Code | 8471.80.40.00 |
Scope of Delivery
- 1 × PhidgetInterfaceKit 2/2/2 (1011_0)
- 1 × 12-wire harness (replacement cable: 3013_0, available separately)
